Die-cast aluminium body with baked (220°C) polyester powder-coat finish, with enhanced treatment option available for coast projects. 9.5kg, 0.04m² surface scx.
Rotatable mount accepts Ø60mm OD pole top or side entry spigots. Pole top version configurable to 0°, 5°, or 10° tilt. Side entry version configurable to 0°, -5°, or -10° tilt relative to bracket to absorb arm upcast for horizontal cutoff.

Three LED arrays configured for a total of eight output levels delivered into a choice of nine beam spreads. Flat tempered glass.

Integrated, replaceable DALI smart driver, programmable for various intelligent control options including Constant Light Output (CLO) feature designed to negate lumen depreciation by small increases in the forward current to the LEDs over lifetime. When implemented correctly, CLO allows designers to create a lighting layout that never requires more power or luminaires than is needed to illuminate the project to design levels.
6kV surge protection between phase-neutral and earth.
SPD (surge protection device) 10kV-5kA between phase-neutral and earth to be provided by installer at the base of the pole.

Wattage: 19W - 110W

High quality, high efficiency Zhaga standard LED modules in 2200K Ra70, 2700K Ra80, 3000K Ra80, 4000K Ra70, or Blue Depleted. L80 @ 120,000hr+ for @350mA @Tq=25°C.

Lumen output: 1800lm - 12,000lm
