COI compliant IP65 from below
The Theatre series of LED panel luminaires deliver high performance and low glare in an IP65 (below ceiling) solution. Anti-microbial treatment applied to exposed underside of fixture. Supplied standard for plaster recessing, or suitable for Bondor ceilings with extended mounting bracket accessory.
Key features
- COI compliant IP65 (from below) LED panel luminaire
- Anti-microbial treatment to underside of fixture
- Mounting options for plaster and Bondor recessing
Luminaire overview
Design
Low profile extruded aluminium luminaire frame, double gasketed, white powdercoated. Anti-microbial treatment applied to exposed underside of luminaire.
Optic
Low glare, high output opalescent optic.
Electrical
Choice of either fixed output or DALI dimmable remote electronic driver, with quick-connect plug.
Wattage: 60W
Light source
Highly efficient LED source, 4000K, CRI 90.
Lumen output: 6800lm
Product Configurator
| Product | Family | Output (lm) | Watts | CCT | Mounting Type | Control | Actions |
|---|---|---|---|---|---|---|---|
Theatre Plaster Recessed 1200x300mm (nom.) Opal DALI Dimmable 1400mA 4000K Ra90
THEATRE.LDH.4090.22
| Theatre | 6700 | 60 | 4000K | Plaster Recessed | DALI Dimmable |
Add to Project Briefcase
|
Theatre Plaster Recessed 1200x300mm (nom.) Opal Fixed Output 1400mA 4000K Ra90
THEATRE.L1H.4090.22
| Theatre | 6700 | 60 | 4000K | Plaster Recessed | Fixed Output |
Add to Project Briefcase
|
Theatre Bondor Recessed 1200x300mm (nom.) Opal Fixed Output 1400mA 4000K Ra90
THEATRE.L1H.4090.22/BONDOR
| Theatre | 6700 | 60 | 4000K | Bondor Recessed | Fixed Output |
Add to Project Briefcase
|
Theatre Bondor Recessed 1200x300mm (nom.) Opal DALI Dimmable 1400mA 4000K Ra90
THEATRE.LDH.4090.22/BONDOR
| Theatre | 6700 | 60 | 4000K | Bondor Recessed | DALI Dimmable |
Add to Project Briefcase
|
