Product details

Optical
Output Lm
35,580
Efficacy (lm/W)
111
Downward Output
34590
Upward Output
990
Light Distribution Up %
3
Light Distribution Down %
97
CCT
4000K
CRI
80
L70
>55,000hr
L80
>55,000hr
L90
47,600hr
TM-21 @ 50,000hr
0.8957
Beam Spread
93 x 103
Horizontal Beam Angle
95
Vertical Beam Angle
105
IES Classification
Type V
BUG Rating
B5-U4-G3
Max Intensity (cd)
12,400.93
Max UGR
28
Luminous Length (X)
550
Luminous Width (Y)
550
Luminous Height (Z)
60
Physical
Finish Colour
Silver Gear Housing
Housing Material
Extruded, anodised aluminium LED module housing. Die-cast gear housing, sealed and powdercoated
Optic Material
Precision designed spun aluminium reflector combined with specialised multi-section radial-prismatic polycarbonate refractor
Luminaire Weight (Net)
14kg
Mounting Type
Suspended
Dimensions
572mm x 490mm
IP Rating
IP65
Electrical
Watts
322
Rated Voltage
220-240V
Electrical Class
Class I
Driver Description
Integral DALI Dimmable Driver programmed for Constant Light Output
Control
DALI Dimmable
Forward Current Rating
1,400
Driver Mounting
Integral
Driver IP Rating
66
CLO
Yes
Number of Drivers
1
Certifications
Warranty
5 Years
