Product details

Optical
Output Lm
1,860
Efficacy (lm/W)
89
Downward Output
1860
Upward Output
0
Light Distribution Up %
0
Light Distribution Down %
100
CCT
4000K
CRI
90
L70
>90,000hr
L80
>90,000hr
L90
46,000hr
TM-21 @ 50,000hr
0.9815
Beam Spread
113 x 114
Horizontal Beam Angle
115
Vertical Beam Angle
115
IES Classification
Type VS
BUG Rating
B1-U0-G1
Max Intensity (cd)
639.65
Max UGR
22
Luminous Length (X)
529
Luminous Width (Y)
529
Luminous Height (Z)
0
Physical
Finish Colour
White
Housing Material
Low profile extruded aluminium luminaire frame, double gasketed, white powdercoated. Anti-microbial treatment applied to exposed underside of luminaire. Bondor ceiling brackets (up to 100mm depth).
Optic Material
Low glare, high output opalescent optic
Luminaire Weight (Net)
3.435kg
Mounting Type
Recessed
Cut Out Size
580mm x 580mm
Dimensions
596mm x 596mm
IP Rating
IP65
IK Rating
IK04
Electrical
Watts
21
Rated Voltage
220-240VAC
Electrical Class
Class II
Driver Description
Remote DALI Dimmable Driver
Control
DALI Dimmable
Forward Current Rating
500
Driver Mounting
Remote
Driver IP Rating
20
Number of Drivers
1
Certifications
Warranty
5 Years
