Product details

Optical
Output Lm
1,880
Efficacy (lm/W)
90
Downward Output
1880
Upward Output
0
Light Distribution Up %
0
Light Distribution Down %
100
CCT
4000K
CRI
90
L70
>90,000hr
L80
>90,000hr
L90
46,000hr
TM-21 @ 50,000hr
0.9815
Beam Spread
113 x 114
Horizontal Beam Angle
115
Vertical Beam Angle
115
IES Classification
Type VS
BUG Rating
B1-U0-G1
Max Intensity (cd)
649.3
Max UGR
22
Luminous Length (X)
229
Luminous Width (Y)
1129
Luminous Height (Z)
0
Physical
Finish Colour
White
Housing Material
Low profile extruded aluminium luminaire frame, double gasketed, white powdercoated. Anti-microbial treatment applied to exposed underside of luminaire
Optic Material
Low glare, high output opalescent optic
Luminaire Weight (Net)
3.6kg
Mounting Type
Recessed
Cut Out Size
1180mm x 280mm
Dimensions
1195mm x 295mm x 67mm
IP Rating
IP65
IK Rating
IK04
Electrical
Watts
21
Rated Voltage
220-240VAC
Electrical Class
Class II
Driver Description
Remote Phase-Cut Dimmable Driver
Control
Phase-Cut Dimmable
Forward Current Rating
500
Driver Mounting
Remote
Driver IP Rating
20
Number of Drivers
1
Certifications
Warranty
5 Years
